Knee Diverter: Service and Repair

Driver Knee Bolster Reinforcement Replacement

Removal Procedure

1. Remove the instrument panel insulator.
2. Pull the bolster trim panel out and downward in order to release the clips securing the panel to the instrument panel.

3. Remove the bolts securing the bolster bracket to the instrument panel.

Installation Procedure
