Aveo L4-1.6L (2008)
Cross-Member: Service and Repair
Front Suspension Crossmember Replacement
Removal Procedure
1. Raise and support the vehicle. Refer to Lifting and Jacking the Vehicle (See: Wheels and Tires/Vehicle Lifting/Service and Repair).
2. Remove the front tire and wheel assemblies. Refer to Tire and Wheel Removal and Installation (See: Wheels and Tires/Service and Repair).
3. Remove the control arm ball joint and stabilizer shaft link nut, lower.
4. Remove the tie rod end ball joint.
5. Remove the engine mounting reaction rod bolts.
6. Drain the power steering fluid.
7. Remove the power steering pipe fittings.
8. Remove the intermediate shaft lower joint.
