Wiper Arm: Adjustments

Windshield Wiper Arm Adjustment

Measuring point for windscreen wiper arms:

Upper edge of water deflector (rubber lip) to wiper arm attachment point.

Note:  Position the wiper arm to the basic setting.

1. Driver side (a) approximately 6.5 cm (2.6 in)
2. Passenger side (b) approximately 8.5 cm (3.3 in).
