8. Remove bolt and nut fastening spring link to crossmember (Fig. 24).
9. Remove spring link.
INSTALLATION
1. Guide ball joint end of spring link into mounting pocket of knuckle, then swing opposite end up to bushing in crossmember and install bolt and nut
fastening spring link to crossmember (Fig. 24). Do not tighten bolt at this time.
NOTE: Prior to using Special Tool 9050A, lubricate Bolt threads to provide ease of use and promote tool longevity.
2. Place new knuckle sleeve onto Installer Bolt, Special Tool 9050-4, and slide it up to Bolt's head (Fig. 25).
3. Install NEW sleeve in knuckle as follows:
