Q009 driver''s air bag

Make

Fiat

Model

Doblò Factory Service Manual

Year

2000–2010

Section

Safety devices › Q009 driver''s air bag

Connectors and pin-outsQ009 driver''s air bag

Q009 DRIVER''S AIR BAG

1.4 8v, 1.6 16v, 1.3 JTD 16V, 1.9 JTD 8V · from 12/03 · MY 2005

Wiring	Colour
See 20 DASHBOARD	NERO

Pin	Cable		Destination
	Sec.	Colour	Node	Connect.	Pin
1	0,5	L		See M060A AIR BAG CONTROL UNIT (FACIA)	21
2	0,5	MB		See M060A AIR BAG CONTROL UNIT (FACIA)	22

Q9 – Facia

1.2 8v, 1.6 16v, 1.3 JTD 16V, 1.9 JTD 8V, 1.9 DIESEL

Wiring	Colour
See 20 DASHBOARD	nero

Pin	Cable		Destination
	Sec.	Colour	Node	Connect.	Pin
1	0,5	L		See Q10 CLOCK SPRING ON STEERING WHEEL	A8
2	0,5	MB		See Q10 CLOCK SPRING ON STEERING WHEEL	B8
