Connectors and pin-outsA020 starter motor

A020 STARTER MOTOR

A020A – Battery positive

1.4 8v, 1.6 16v, 1.3 JTD 16V, 1.9 JTD 8V · from 12/03 · BIPOWER, MY 2005

Wiring	Colour
See 41 BATTERY POSITIVE	_

Pin	Cable		Destination
	Sec.	Colour	Node	Connect.	Pin
	30	R		See A001B BATTERY (BATTERY POSITIVE)

A020B – Recharging

1.3 JTD 16V, 1.9 JTD 8V · from 12/03 · MY 2005

Wiring	Colour
See 45 RECHARGING	_

Pin	Cable		Destination
	Sec.	Colour	Node	Connect.	Pin
	16	R		See A010B ALTERNATOR (RECHARGING)

1.4 8v, 1.6 16v · from 12/03 · MY 2005

Wiring	Colour
See 45 RECHARGING	_

Pin	Cable		Destination
	Sec.	Colour	Node	Connect.	Pin
	10	R		See A010B ALTERNATOR (RECHARGING)

A020C – Engine

1.6 16v, 1.9 JTD 8V · from 12/03 · BIPOWER, MY 2005

Wiring	Colour
See 50 ENGINE	_

Pin	Cable		Destination
	Sec.	Colour	Node	Connect.	Pin
1	1,5	M		See B001F JUNCTION UNIT (INJECTION BRAID / ENGINE SERVICES)	19

1.4 8v · from 12/03 · MY 2005

Wiring	Colour
See 50 ENGINE	_

Pin	Cable		Destination
	Sec.	Colour	Node	Connect.	Pin
1	2,5	MB		See D029 ENGINE CABLES/ENGINE SERVICES CABLE COUPLING	6

1.3 JTD 16V · from 12/03 · MY 2005

Wiring	Colour
See 50 ENGINE	_

Pin	Cable		Destination
	Sec.	Colour	Node	Connect.	Pin
1	1,5	M		See D029 ENGINE CABLES/ENGINE SERVICES CABLE COUPLING	6

A20A – Battery positive

1.2 8v

Wiring	Colour
See 41 BATTERY POSITIVE

Pin	Cable		Destination
	Sec.	Colour	Node	Connect.	Pin
	16	R		See A1B BATTERY ( BATTERY POSITIVE )

1.9 DIESEL

Wiring	Colour
See 41 BATTERY POSITIVE

Pin	Cable		Destination
	Sec.	Colour	Node	Connect.	Pin
	30	R		See A1B BATTERY ( BATTERY POSITIVE )

A20B – Recharging

1.2 8v

Wiring	Colour
See 45 RECHARGING

Pin	Cable		Destination
	Sec.	Colour	Node	Connect.	Pin
	10	R		See A10B ALTERNATOR ( RECHARGING )

1.9 DIESEL

Wiring	Colour
See 45 RECHARGING

Pin	Cable		Destination
	Sec.	Colour	Node	Connect.	Pin
	16	R		See A10B ALTERNATOR ( RECHARGING )

A20C – Engine

1.2 8v, 1.6 16v, 1.3 JTD 16V, 1.9 JTD 8V, 1.9 DIESEL

Wiring	Colour
See 50 ENGINE

Pin	Cable		Destination
	Sec.	Colour	Node	Connect.	Pin
1	1,5	M		See B1F ENGINE COMPARTMENT JUNCTION UNIT ( ENGINE )	19

1.3 JTD 16V

Wiring	Colour
See 50 ENGINE

Pin	Cable		Destination
	Sec.	Colour	Node	Connect.	Pin
1	1,5	M		See B1F ENGINE COMPARTMENT JUNCTION UNIT ( ENGINE )	19
