Timing Belt: Adjustments (page 6 of 16)
- Make
- Hyundai
- Model
- Tucson AWD
- Engine
- L4-2.0L
- Year
- 2007
- Section
- Timing Belt
MaintenanceAdjustments · page 6 of 16
3) Remove the bolt (B) and stay plate (A).
5. Temporarily loosen the water pump pulley bolts.
6. Remove alternator belt.
7. Remove air compressor belt.
8. Remove power steering belt.
9. Remove 4bolts and water pump pulley.
10. Remove the 4bolts and timing belt upper cover.
11. Turn the crankshaft pulley, and align its groove with timing mark T of the timing belt cover.
12. Remove the crankshaft pulley bolt (B) and crankshaft pulley(A).
