Timing Belt: Specifications (page 11 of 11)
- Make
- Kia
- Model
- Sephia LS
- Engine
- L4-1.8L
- Year
- 2001
- Section
- Timing Belt
MaintenanceSpecifications · page 11 of 11
14. Install timing belt guide plate and crankshaft pulley.
Tightening torque: 9.0 - 12.6 ft. lbs. (12.3 - 17.2 Nm, 1.3 - 1.8 kg-m)
15. Install water pump pulley.
Tightening torque: 9.0 - 12.6 ft. lbs. (12.3 - 17.2 Nm, 1.3 - 1.8 kg-m)
16. Install generator belt and adjust the tension.
17. Install P/S and/or A/C drive belt and adjust the tension.
18. Connect negative battery cable.
