Discovery II
PANEL REPAIRS
77-2-36 REPAIRS
Refit
1. Fit insulation pad to engine bulkhead.
2. Fit front door aperture seal.
3. Position front carpet and fit tread plate to front
door aperture.
4. Fit wiring to 'A' post.
5. Driver's side: Fit steering column support
bracket.
6. Fit fascia.
7. RH side: Fit CD autochanger.
8. Fit RH or LH front seat.
9. Fit sunroof drain tube.
10. Connect multiplug to speaker (if fitted) and fit
finisher to 'A' post.
11. Diesel models: Fit ECM.
Td5, REPAIRS, Engine control module
(ECM).
12. Fit windscreen.
13. Fit sill finisher.
14. Fit front door.
15. Fit front wing.
16. Fit bonnet.
17. Connect leads/multiplug to alternator.
18. Connect battery leads, negative lead last.
