Discovery II
PANEL REPAIRS
REPAIRS 77-2-37
Dash side assembly
NOTE: In this procedure, the front wing, 'A' post
assembly and the valance outer reinforcement (rear
section) are replaced in conjunction with the dash
side assembly.
Remove
1. Disconnect both battery leads, negative lead
first.
2. Disconnect leads/multiplug from alternator.
3. Remove 'A' post assembly.
PANEL REPAIRS, REPAIRS, 'A' post
Repair
1. Remove existing panel(s), prepare panel joint
faces and install new panel(s) in accordance
with Panel Replacement Procedure. Punch or
drill holes in new panel for plug welding as
shown.
Refit
1. Fit 'A' post assembly.
PANEL REPAIRS, REPAIRS, 'A' post
2. Connect leads/multiplug to alternator.
3. Connect battery leads, negative lead last..
M77 1691
M77 1696B
