Discovery II
PANEL REPAIRS
77-2-30 REPAIRS
Refit
1. Fit harness to valance.
2. Fit and secure expansion tank to fixings.
3. Fit fuse box.
4. Fit battery tray.
5. Fit battery.
6. Fit front wing.
7. Connect leads/multiplug to alternator.
8. Connect battery leads, negative lead last.
Valance upper assembly (front section) -
LH
In this procedure, the front wing, the valance outer
reinforcement (front section) and the bonnet alarm
switch mounting bracket are replaced in conjunction
with the LH valance upper assembly (front section).
Remove
1. Disconnect both battery leads, negative lead
first.
2. Disconnect leads/multiplug from alternator.
3. Remove front wing.
4. Remove air filter assembly.
Td5, REPAIRS, Air filter assembly.
V8, REPAIRS, Air cleaner assembly.
5. Remove PAS/ACE reservoir.
6. Remove ABS modulator.
BRAKES, REPAIRS, Modulator unit
7. Release harness from valance and position
aside.
8. Models with A/C: Depressurise A/C system
and remove pipes from valance.
RECOVERY, RECYCLING AND
RECHARGING, Refrigerant recovery,
recycling and recharging.
