Freelander Service Procedures
PANEL REPAIRS
77-2-58 REPAIRS
Rear floor crossmember assembly
Remove
1. Disconnect battery earth lead.
2. Disconnect alternator.
3. Disconnect all ECUs.
4. Remove tail door.
assembly - remove for access & refit.
5. Remove tail door aperture seal.
6. Remove LH and RH rear quarter lower casings.
REPAIRS, Trim casing - rear quarter - lower
- 5 door.
7. Remove loadspace carpet.
REPAIRS, Carpet - luggage compartment.
8. Release vehicle harness from rear body lower
closing and position aside.
Repair
1. Remove existing panel(s), prepare panel joint
faces and install new panel(s) in accordance
with Panel Replacement Procedure. Punch or
drill holes in new panel for plug welding as
shown.
Refit
1. Secure vehicle harness to rear body lower
closing.
2. Fit loadspace carpet.
REPAIRS, Carpet - luggage compartment.
3. Fit LH and RH rear quarter lower casings.
REPAIRS, Trim casing - rear quarter - lower
- 5 door.
4. Fit tail door aperture seal.
5. Fit tail door.
assembly - remove for access & refit.
6. Connect all ECUs.
7. Connect alternator.
8. Connect battery earth lead.
