Freelander Service Procedures
PANEL REPAIRS
REPAIRS 77-2-61
Front roof assembly - 3 door
Remove
1. Disconnect battery earth lead.
2. Disconnect alternator.
3. Disconnect all ECUs.
4. Remove LH and RH front roof panel finishers.
5. Remove headlining.
6. Remove sunroof assembly.
roof - complete - front - 3 door.
7. Remove windscreen.
Repair
1. Remove existing panel(s), prepare panel joint
faces and install new panel(s) in accordance
with Panel Replacement Procedure. There are
no plug welds used in this procedure, spot
welds only.
Refit
1. Fit windscreen.
2. Fit sunroof.
roof - complete - front - 3 door.
3. Fit headlining.
4. Fit LH and RH front roof panel finishers.
5. Connect all ECUs.
6. Connect alternator.
7. Connect battery earth lead.
Rear roof assembly - 3 door
Remove
1. Disconnect battery earth lead.
2. Disconnect alternator.
3. Disconnect all ECUs.
4. Remove soft/hard top.
5. Remove LH and RH rear roof panel finishers.
6. Remove headlining.
7. Remove sunroof.
roof - complete - front - 3 door.
8. Remove aerial.
REPAIRS, Aerial - manual - 3 door.
Repair
1. Remove existing panel(s), prepare panel joint
faces and install new panel(s) in accordance
with Panel Replacement Procedure. There are
no plug welds used in this procedure, spot
welds only.
Refit
1. Fit aerial.
REPAIRS, Aerial - manual - 3 door.
2. Fit sunroof.
roof - complete - front - 3 door.
3. Fit headlining.
4. Fit LH and RH rear roof panel finishers.
5. Fit soft/hard top.
6. Connect all ECUs.
7. Connect alternator.
8. Connect battery earth lead.
