L322 Range Rover Service Procedures
DRIVESHAFTS
REPAIRS
47-19
9. Supporting drive shaft joint, use LRT-12-076 to
remove joint from drive shaft.
10. Remove and discard joint retaining ring from
drive shaft.
11. Remove gaiter from drive shaft.
Refit
1. Clean drive shaft and joint.
2. Fit gaiter to drive shaft.
3. Fit new joint retaining ring to drive shaft.
4. Ensure reference marks are aligned and fit joint
to drive shaft.
5. Fit new circlip to drive shaft.
6. Apply grease from the sachet to the joint.
7. Position gaiter to joint and secure to joint and
shaft with new clips.
8. Fit new dust cover to drive shaft.
9. Fit rear drive shaft.
