LR3/Disco 3
Right-hand drive vehicles
Right-hand drive vehicles
All vehicles
Lower the engine onto its mount.
Tighten the nut to 90 Nm (66 lb.ft).
6 .
Raise the vehicle.
7 .
Install the exhaust system.
Clean the component mating faces.
Install new bolts and tighten to 40 Nm (30 lb.ft).
8 .
Install the engine undershield. For additional information, refer to
Engine Undershield (76.10.50)
(Section 501-02)
9 .
Lower the vehicle.
1 .
NOTE :
Apply petroleum jelly to the battery terminals.
Connect the battery positive cable.
Clean the component mating faces.
Install the grommet.
Tighten the clamp nut to 10 Nm (7 lb.ft).
1 .
Secure the wiring harness clip.
Tighten the bolt to 10 Nm (7 lb.ft).
1 .
Install the engine cover. For additional information, refer to
Engine Cover - 4.0L (12.30.50)
(Section
501-05)
2 .
Connect the battery ground cable. For additional information, refer to
Specifications
(Section 414-00)
