LR3/Disco 3
2 .
Early vehicles only: Remove excess material from the outside edges of the 6 intake manifold flange
faces; file to within 2 mm of the gasket edge.
3 .
Early vehicles only: Install the fuel rail and injectors.
Clean the component mating faces.
Tighten the bolts to 25 Nm (18 lb.ft).
Connect the fuel injector electrical connectors.
Tighten the M6 bolt to 10 Nm (7 lb.ft).
4 .
Install the intake manifold tuning valve.
Clean the component mating faces.
Install a new O-ring seal.
Tighten the bolts to 10 Nm (7 lb.ft).
5 .
Secure the HT leads to the intake manifold with clips.
6 .
NOTE :
Note the fitted position of the fasteners.
Install the 4 ignition coils.
Tighten the bolts to 6 Nm (4 lb.ft).
Tighten the studs to 6 Nm (4 lb.ft).
Connect the HT electrical connections.
