LR3/Disco 3
2 .
Evenly and progressively tighten the bolts in the sequence shown to 12 Nm (9 lb.ft).
3 .
Install the crankshaft front oil seal. For additional information, refer to
Crankshaft Front Seal
(12.21.14)
(Section 303-01)
4 .
Install the LH valve cover. For additional information, refer to
Valve Cover LH (12.29.43)
(Section
303-01)
5 .
Install the RH valve cover. For additional information, refer to
Valve Cover RH (12.29.44)
(Section
303-01)
6 .
Install the generator mounting bracket.
Clean the locating dowels.
Clean the component mating faces.
Tighten the bolts to 45 Nm (33 lb.ft).
7 .
Install the generator.
Clean the component mating faces.
Tighten the bolts to 48 Nm (35 lb.ft).
8 .
Connect the battery positive cable.
Tighten the nut to 10 Nm (7 lb.ft).
Secure the cover.
9 .
Install the RH exhaust manifold heat shield.
Tighten the screws.
