Range Rover P38
57
STEERING
NEW RANGE ROVER
8
REPAIR
7. Remove banjo bolt securing pump return hose to
steering box and discard 2 washers.
CAUTION: Plug the connections.
8. Remove nut securing PAS hose brackets to
steering box.
9. Release PAS hose brackets from stud.
10. Release PAS pipe from 2 radiator lower bracket
clips.
11. Remove pump return hose.
Refit
12. Position return hose to vehicle.
13. Remove plugs from hose and PAS fluid
reservoir.
14. Clean hose and PAS pump union.
15. Connect return hose union to PAS fluid reservoir
and secure with clip.
16. Remove plugs from hose and steering box.
17. Clean hose and steering box union.
18. Position PAS hose brackets to steering box and
secure with nut.
19. Fit banjo bolt and NEW washers to return hose
and fit to steering box. Tighten banjo bolt to
50
Nm (37 lbf.ft)
20. Position return hose and secure to radiator lower
bracket clips.
21. Bleed steering system.
See this section.
22. Remove stand(s) and lower vehicle.
