6 V6-3.0L (2007)
Alignment: Specifications
Rear Wheel Alignment
Wagon
WAGON REAR SUSPENSION
TOTAL TOE-IN
Tire: ............................................................................................................................... 2±4 mm(0.08±0.16 in.), Rim inner: 1.4±2.8 mm (0.06±0.12 in.)
(degree) ........................................................................................................................................................................................................... 0°11'±0°22'
CAMBER ANGLE
Fuel gauge indication
Empty ............................................................................................................................................................................................................ -0°59'±1°
1/4 ................................................................................................................................................................................................................. -1°00'±1°
1/2 ................................................................................................................................................................................................................. -1°02'±1°
3/4 ................................................................................................................................................................................................................. -1°04'±1°
Full ................................................................................................................................................................................................................ -1°06'±1°
Difference between left and right must not exceed 1°30'.
THRUST ANGLE 0°±0°48'
