Flex Plate: Specifications
[FS5A-EL]
DRIVE PLATE INSTALLATION [FS5A-EL]
Tighten the new drive plate mounting bolts in two or three steps in the order shown.
Tightening torque 108 - 116 N-m (11.0 - 11.8 kgf-m, 79.7 - 85.5 ft-lbf)
