Flex Plate: Specifications
- Make
- Mazda
- Model
- CX-7
- Engine
- L4-2.3L Turbo
- Year
- 2007
- Section
- Flex Plate › Specifications
Transmission and DrivetrainSpecifications · page 1 of 3
Flex Plate: Specifications
DRIVE PLATE
Tighten the new drive plate mounting bolts in two or three steps in the order shown.
Tightening torque ............................................................................................................................ 108 - 116 Nm (11.0 - 11.8 kgf-m, 79.7 - 85.5 ft-lbf)
