Mazdaspeed6 L4-2.3L Turbo (2006)
1. Park the vehicle on level ground.
2. Remove the filler plug and gasket.
3. Verify that the oil is near the brim of the plug port. If the oil level is low, add the specified amount and type of oil through the filler plug hole.
Manual transaxle oil [A65M-R]
Specified oil grade: API Service GL-4 or GL-5
Specified oil viscosity: SAE 75W-90
4. Install a new gasket and the filler plug.
Tightening torque 30.0 - 39.0 Nm (3.1 - 3.9 kgf-m, 22.1 - 28.8 inch lbs.)
Transaxle Oil Replacement [A65M-R]
TRANSAXLE OIL REPLACEMENT [A65M-R]
A65M-R
1. Remove the drain plug with the gasket.
2. Drain the oil into a suitable container.
3. Install a new gasket and the drain plug.
Tightening torque 30.0 - 39.0 Nm (3.1 - 3.9 kgf-m, 22.1 - 28.8 inch lbs.)
4. Remove the filler plug with gasket and add the specified amount and type of oil through the filler plug hole until the level reaches the bottom of
the filler plug hole.
Manual transaxle oil [A65M-R]
Specified oil grade: API Service GL-4 or GL-5
Specified oil viscosity: SAE 75W-90
Capacity (approximate quantity): 2.3 Liters (2.4 US quarts, 2.0 Imp quarts)
5. Install a new gasket and the filler plug.
Tightening torque 30.0 - 39.0 Nm (3.1 - 3.9 kgf-m, 22.1 - 28.8 inch lbs.)
Transaxle Oil Inspection [A26MX-R]
TRANSAXLE OIL INSPECTION [A26MX-R]
A26MX-R
