Protege L4-1.5L DOHC (1995)

  • Maintenance
  • Timing Belt
  • Component Information
  • Specifications
  • Timing Belt Deflection

Page 1
background image

Timing Belt: Specifications



Timing Belt Deflection 0.28 - 0.35 in at 22 lbf
