Tribute DX 4WD L4-2.0L (2001)
Vehicle Lifting: Locations
Jacking Position
WARNING:
-
Do not run the engine when jacking the vehicle. The wheels contacting the ground could cause the vehicle to move.
-
Make sure the jack and jack stands are correctly located to prevent the vehicle from falling.
-
Wheel chocks should be used to prevent the vehicle from rolling and falling off the jack.
Jacking Points - Front
1. The jacking point is a tab that extends from the front suspension lower control arm at the bolt head of the lower control arm.
Jacking Points - Rear
1. The rear jacking points are located on the rear axle.
