Colour: GREY Gender: Female
- Make
- MG
- Model
- MGF Electrical Library
- Year
- 2001 model year on
- Section
- C0448 Main harness to engine harness › Colour: GREY Gender: Female
ConnectorsColour: GREY Gender: Female
| Cav 1 | Col BU | Cct 8 |
| 2 | BR | 8 |
| 3 | UW | 8 |
| 4 | UR | 8 |
| 5 | UY | 8 |
| 6 | US | 8 |
| 7 | WN | ALL |
| 8 | NK | ALL |
| 9 | NK | ALL |
| 10 | NR | ALL |
Description: Main harness to engine harness Location: LH side of engine compartment
Colour: GREY Gender: Female
