Rain Sensor: Locations
- Make
- Pontiac
- Model
- G8
- Engine
- V8-6.0L
- Year
- 2009
- Section
- Rain Sensor › Locations
Wiper and Washer SystemsLocations
Rain Sensor: Locations
Harness Routing Views
Headliner Wiring (Left Hand Drive)
1 - Centre High Mounted Stop Lamp (CHMSL) Connector - E79
2 - Digital Video Player (DVD) Connector - A152
3 - Dome Lamp - Rear Connector - E94
4 - Sunroof Switch Connector - S228
5 - Sunroof Control Module Connector - A108
6 - Dome Lamp Connector - E67
7 - Left Sunshade Connector - E120
8 - Headliner to I/P Harness Connector - X212
9 - Headliner to I/P Harness Connector - X213
10 - Outside Moisture Sensor Connector - A121
11 - Right Sunshade Connector - E120
