INLET AND EXHAUST MANIFOLD - ’K8’

1. Inlet manifold chamber
2. Gasket - manifold to inlet chamber
3. Inlet manifold
4. Gasket - manifold to cylinder head
5. Gasket - manifold to block
6. Exhaust manifold
7. Gasket - manifold to front pipe
8. Self-locking nut
9. Flange nut
10. Flange bolt - manifold to cylinder head
11. Flange nut
12. Flange bolt - inlet chamber to manifold
