Male

Make

Rover

Model

400 Electrical Library

Year

1998 model year on

Section

C0612 › Male

ConnectorsMale · page 1 of 2

Main harness to engine compartment harness

Male

LIGHT GREY

Behind LH side of fascia

Cav	Col	CCT
1	YR	69
2	Y	69
3	YU	69
4	RW	69
5	RU	69
6	RB	69
7	GU	69
8	GW	69
9	BG	69
10	GB	69
11	U	69
12	UW	69

Cav	Col	CCT
13	UY	69
14	NB	9
15	GO	9
16	UB	69

05 General
