Torque settings

Headlamp setting – vehicle unladen 0°8' ± 0°2' below horizontal and parallel

TORQUE SETTINGS

• Alternator pulley locknut – 1.4 and 1.6 25 Nm
• Alternator mounting bolts – 1.4 and 1.6 25 Nm
• Alternator heat shield nut and bolts – If fitted 6 Nm
• Support bracket to starter motor, bolts 1.4 and 1.6 25 Nm
• Starter motor support bracket to gearbox, bolts 1.4 and 1.6 25 Nm
• Starter motor support bracket to engine bolt – 1.4 and 1.6 45 Nm
• Alternator pulley nut – 2.0 75 Nm
• Alternator mounting bolts – 2.0 25 Nm
• Coolant rail to cylinder block, bolt – 2.0 25 Nm
• Starter motor to engine, bolts – 2.0 85 Nm
• Starter solenoid nut – 2.0 4 Nm
• Radiator mounting bracket bolt – 2.0 5 Nm
• Drive belt tensioner bolt – 2.0 45 Nm
• Engine R.H. mounting to engine, bolts – 2.0 55 Nm
• Engine R.H. mounting nut – 2.0 85 Nm
• Radiator top hose clip – 2.0 – Air conditioning 3.5 Nm
• Roof lamp screws – Non Cabriolet 5 Nm
