Suspension: Description and operation (page 2 of 3)

L.H. side illustrated

1. Damper mounting cap*
2. Self locking nut
3. Washer
4. Locknut – mounting to body
5. Damper mounting base plate
6. Bearing
7. Spring seat – upper
8. Dust cover
9. Coil spring
10. Washer
11. Bump stop rubber or Spring aid*
12. Damper strut
13. Bolt – strut to hub
14. Tie rod
15. Bolt – tie rod to lower arm
16. Nut – tie rod to cross member
17. Flanged washer – tie rod
18. Bush – tie rod
19. Collar bushes
20. Drive shaft nut
21. Brake disc
22. Screw – brake disc to drive flange
23. Drive flange
24. Disc shield
25. Screw – disc shield to hub
26. Bearing circlip
27. Hub bearing
28. Hub
29. Drive shaft
30. Lower arm
31. Ball joint nuts
32. Lower arm bush
33. Bolt – lower arm to body
34. Anti-roll bar link
35. Bolt
36. Nut – link bolt
37. Bolt – link to lower arm
38. Anti-roll bar
39. Anti-roll bar bush
40. Bush clamp
41. Screw – clamp to body
42. Split pin
43. Steering arm
44. Spacer*

* Where fitted
