Coolant Line/Hose: Service and Repair

Engine Coolant Air Bleed Hose Replacement

Special Tools

SA9111E  Constant Force Clamp Pliers

Removal Procedure

1. Reposition the air bleed hose clamp at the surge tank using SA9111E  .
2. Remove the air bleed hose from the surge tank.
3. Reposition the air bleed hose clamp at the engine using SA9111E  .
4. Remove the heater hoses from the engine.

Installation Procedure
