Accelerator pedal module with accelerator pedal position senderG79 and accelerator pedal position sender 2G185: Removing and installing

Accelerator pedal module with accelerator pedal position sender -G79- and accelerator pedal position sender 2 -G185-: Removing and installing

t	Removing → Anchor

t	Fitting → Anchor

t	Tightening torques → Anchor

Check the tool and equipment equivalence table according to the applicability between Seat / VW / Audi / Skoda → Chapter

Special tools and workshop equipment required

t	Pressure tool -T10238- (left guide vehicles), see equivalent → Anchor

t	Pressure tool -T10240- (right guide vehicles), see equivalent → Anchor

Removing

–	Remove the steering column cover -arrows-.

–	Lift the cover using a screwdriver as a lever.

–	Remove the bolt on the bottom.

–	Insert the pressure tool -T10238- (left-hand drive vehicles) or the pressure tool -T10240- (right-hand drive vehicles) in the space on the accelerator pedal module, as shown in the diagram.

–	Remove the connector from the accelerator pedal module.

–	Disconnect the electrical connection -2-; to do this, press the release tab in all the way -arrow-.

–	Remove the cable guide -1- from the accelerator pedal module, if there is one.

Installing

Fit in reverse order from removal, remembering the following:

–	Attach cable guide clip -1- and electrical connector -2- to accelerator pedal module -5-.

l	The connector should snap into place.

–	Insert the accelerator pedal module into the attachment pins -6-.

–	Fit the centre fastener -7- in the hole on the vehicle floor.

–	Secure the accelerator pedal module using the bolt -3- and fit the cover -4-.

–	Remove the steering column cover.

Tightening torques

Component		Nm
Accelerator pedal module to bodywork		9
