02R, 5-speed manual transmission (Capacity): Technical data
- Make
- SEAT
- Model
- Leon Mk2
- Section
- Technical data › Gearbox identification › Capacity
‹ Prev Code letters, allocation, transmission ratios, capacitiesNext › Overview - power transmission
Power transmissionCapacity
| Capacity |
| Engine code | LBQ | JXY | JDD | KFK, MZL | MUX | MAL, MNY, MZK, MZN |
| Filling quantity | 1.9 litres | |||||
| Specification | gear oil API GL4 SAE 75W in accordance with standard TL 52512 | |||||
| Clutch action | hydraulic | |||||
| Clutch plate Ø mm | 228 | 216 | 228 | 228 | 228 | |
| Differential flanged shaft Ø mm | 108 | 100 | ||||
| I total in top gear | 3.158 x 0.625 = 1.973 | 3.158 x 0.7 = 2.210 | 3.158 x 0.658 = 2.077 | 3.158 x 0.659 = 2.081 | 3.647 x 0.733 = 2.673 | 3.388 x 0.659 = 2.232 |
