Securing the engine to the assembly stand |
Special tools and workshop equipment required |
t
| Lifting device -MP9-201 (2024 A)- |
t
| Engine mount -MP 1-202- |
t
| Assembly stand -MP 9-101- |
t
| Workshop crane, e.g. -VAS 6100- |
Secure the engine with engine mount -MP 1-202- on the assembly stand -MP 9-101- before performing assembly work. |
Vehicles with automatic gearbox |
–
| After separating the gearbox from the engine, secure the torque converter against „dropping down“. |
Continued for all vehicles |
–
| Remove coolant regulator housing from the cylinder head. |
|
|
|
