Skoda Octavia Mk106 · Power transmission
06 · Transmission

Gearbox identification characters (Automatic gearbox 01M)

Make
Skoda
Model
Octavia Mk1
Section
Automatic gearbox 01M › Technical Data › Gearbox identification characters
Power transmissionGearbox identification characters
Gearbox identification characters
Location on the gearbox

Identification characters of the gearbox -arrow 1-
Automatic gearbox 01M -arrow 2-
  S37-0001
Example:DTB02087
 IIII
 IIII
 Identification
characters
DayMonthManufacturing year 1997

Gearbox identification characters (Automatic gearbox 01M) – Skoda Octavia Mk1  Note
The gearbox identification characters also appear on the vehicle data stickers.

The vehicle data sticker is located at the rear left on the floor of the boot.
  V53-1283
