Flywheel: Specifications
Tightening Torque:
Except STi Model
72 N.m (7.3 kgf-m, 52.8 ft-lb)
STi Model
75 N.m (7.6 kgf-m, 55.3 ft-lb)
NOTE:
Tighten the flywheel installing bolts gradually. Each bolt should be tightened to the specified torque in a crisscross fashion.
