Drive Belt: Service and Repair
Removal

1ZZ-FE ENGINE MECHANICAL: DRIVE BELT:

COMPONENTS

REMOVAL

1. REMOVE ENGINE UNDER COVER RH
2. REMOVE FAN AND GENERATOR V BELT
