Radiator Hose: Diagrams

Make

Volkswagen

Model

Cabrio GL

Engine

L4-2.0L (ABA)

Year

2001

Section

Hoses › Radiator Hose › Diagrams

MaintenanceDiagrams · page 1 of 3

Radiator Hose: Diagrams

LEGEND

1

To Upper Radiator

2

O-ring

3

Coolant (Water) Pump

4

Clip

5

Engine Coolant Temperature (ECT) Sensor

6

From Expansion Tank

7

Connector Flange

8

To Heater Core

9

From Expansion Tank

10

Bolt

11

Bracket

12

From Heater Core

13

From Expansion Tank (Manual Trans.) Or ATF Cooler (Automatic Trans.)

14

Coolant Pipe

15

Oil Cooler

16

To Lower Radiator

17

Studs and Bolts

18

Alternator Bracket

19

Nut

20

Poly-Ribbed Drive Belt
