C70 Coupe L5-2.3L Turbo VIN 53 B5234T3 (2001)
-
Drain the system of refrigerant
-
Disconnect pipe/hose from its connector on the member.
-
Raise the car.
-
Remove air baffle.
-
Disconnect pipe/hose from condenser.
Install
-
In reverse order.
Tighten to 25 ±6 Nm.
Replacing refrigerant pipe/hose; member - evaporator
Remove
-
Drain the system of refrigerant
-
Remove control module box fresh air intake hose and exhaust hose.
