Freelander Service Procedures
CHARGING AND STARTING
86-1-8
REPAIRS
Ancillary drive belt - K1.8 without A/C
$% 86.10.03
Remove
1. Disconnect battery earth lead.
2. Remove PAS pump drive belt.
STEERING, REPAIRS, Drive belt -
3. Loosen alternator pivot nut and bolt.
4. Loosen bolt securing alternator adjustment
bracket to engine.
5. Loosen bolt securing alternator to adjustment
bracket.
6. Rotate alternator drive belt adjustment bolt anti-
clockwise to release tension from belt and
remove belt.
Refit
1. Ensure pulleys are clean and damage free.
CAUTION: Examine drive belt for signs of
wear. A drive belt with cracked ribs is
acceptable. A drive belt that has loose or
missing parts of ribs must be changed.
2. Fit drive belt. Ensure belt is located correctly in
pulley grooves.
3. Adjust belt tension.
ADJUSTMENTS, Ancillary drive belt - K1.8.
4. Fit PAS pump drive belt.
STEERING, REPAIRS, Drive belt -
5. Connect battery earth lead.
