A40 Heater plug

Make

Alfa Romeo

Model

147 Factory Service Manual

Year

2000–2004

Section

Starting - recharging › A40 Heater plug

Connectors and pin-outsA40 Heater plug

A40 Heater plug

A40A – Engine

1.9 JTD 16V

Wiring	Colour
50 ENGINE

Pin	Cable		Destination
	Sec.	Colour	Node	Connect.	Pin
	2,5	VN		M15B	1

A40A – Spark plugs

1.9 JTD 8V

Wiring	Colour
85 SPARK PLUGS

Pin	Cable		Destination
	Sec.	Colour	Node	Connect.	Pin
	2,5	HG		M15B	1

A40B – Engine

1.9 JTD 16V

Wiring	Colour
50 ENGINE

Pin	Cable		Destination
	Sec.	Colour	Node	Connect.	Pin
	2,5	VN		M15B	2

A40B – Spark plugs

1.9 JTD 8V

Wiring	Colour
85 SPARK PLUGS

Pin	Cable		Destination
	Sec.	Colour	Node	Connect.	Pin
	2,5	HN		M15B	2

A40C – Engine

1.9 JTD 16V

Wiring	Colour
50 ENGINE

Pin	Cable		Destination
	Sec.	Colour	Node	Connect.	Pin
	2,5	VN		M15B	3

A40C – Spark plugs

1.9 JTD 8V

Wiring	Colour
85 SPARK PLUGS

Pin	Cable		Destination
	Sec.	Colour	Node	Connect.	Pin
	2,5	HV		M15B	3

A40D – Engine

1.9 JTD 16V

Wiring	Colour
50 ENGINE

Pin	Cable		Destination
	Sec.	Colour	Node	Connect.	Pin
	2,5	VN		M15B	4

A40D – Spark plugs

1.9 JTD 8V

Wiring	Colour
85 SPARK PLUGS

Pin	Cable		Destination
	Sec.	Colour	Node	Connect.	Pin
	2,5	HR		M15B	4
