SRX AWD V6-3.6L (2008)
Wiper Switch: Locations
Instrument Panel/Center Console Component Views
Instrument Panel and Floor Console Components (LHD)
1 - Driver Information Center (DIC) Switch
2 - Dimmer Switch
3 - Turn Signal/Multifunction Switch
4 - Inflatable Restraint Steering Wheel Module
5 - Instrument Panel Cluster (IPC)
6 - Windshield Wiper/Washer Switch
7 - Sunload/Ambient Light Sensor
8 - Speaker - Instrument Panel (UQS)
9 - Analog Clock
10 - Radio/CD/DVD/Navigation Unit (UV2)
11 - Inflatable Restraint I/P Module
12 - HVAC Control Module
13 - Rear Window Defogger Switch
14 - Courtesy Lamp - Right Footwell
15 - Hazard Switch
16 - Tow/Haul Switch
