I031 clutch pedal switch

Make

Fiat

Model

Doblò Factory Service Manual

Year

2000–2010

Section

Switches › I031 clutch pedal switch

Connectors and pin-outsI031 clutch pedal switch

I031 CLUTCH PEDAL SWITCH

1.4 8v, 1.3 JTD 16V, 1.9 JTD 8V · from 12/03 · MY 2005, Right hand drive

Wiring	Colour
See 12 FRONT	NERO

Pin	Cable		Destination
	Sec.	Colour	Node	Connect.	Pin
1	0,5	HB		See D004B FRONT/ENGINE JUNCTION (FRONT)	A
2	0,5	N		See C010 LEFT FRONT EARTH	9

1.4 8v, 1.3 JTD 16V, 1.9 JTD 8V · from 12/03 · MY 2005

Wiring	Colour
See 12 FRONT	NERO

Pin	Cable		Destination
	Sec.	Colour	Node	Connect.	Pin
2	0,5	HB		See D004B FRONT/ENGINE JUNCTION (FRONT)	A
4	0,5	N		See C010 LEFT FRONT EARTH	9

I31 – Front

1.2 8v, 1.6 16v, 1.3 JTD 16V, 1.9 JTD 8V, 1.9 DIESEL

Wiring	Colour
See 12 FRONT	nero

Pin	Cable		Destination
	Sec.	Colour	Node	Connect.	Pin
1	0,5	HB		See D4A FRONT/ENGINE COUPLING ( FRONT )
2	0,5	N		See C010 LEFT FRONT EARTH	9

Wiring	Colour
See 12 FRONT	nero

Pin	Cable		Destination
	Sec.	Colour	Node	Connect.	Pin
2	0,5	HB		See D4A FRONT/ENGINE COUPLING ( FRONT )
4	0,5	N		See C010 LEFT FRONT EARTH	9
