I050 inertia switch

Make

Fiat

Model

Doblò Factory Service Manual

Year

2000–2010

Section

Switches › I050 inertia switch

Connectors and pin-outsI050 inertia switch

I050 INERTIA SWITCH

1.4 8v, 1.3 JTD 16V, 1.9 JTD 8V · from 12/03 · MY 2005

Wiring	Colour
See 25 REAR	NERO

Pin	Cable		Destination
	Sec.	Colour	Node	Connect.	Pin
1	1,5	N		See C030 LEFT REAR EARTH	3
3	1,5	M		See N040 FUEL PUMP AND LEVEL GAUGE	3

1.6 16v · from 12/03 · BIPOWER, Doblò trim level, MY 2005

Wiring	Colour
See 25 REAR	NERO

Pin	Cable		Destination
	Sec.	Colour	Node	Connect.	Pin
1	1,5	N		See C030 LEFT REAR EARTH	3
3	1,5	M	X	See N040 FUEL PUMP AND LEVEL GAUGE	3
				See L060B METHANE SUPPLY SOLENOID (REAR)	2
				See L060A METHANE SUPPLY SOLENOID (REAR)	2
				See D006 FRONT/REAR COUPLING	1

1.6 16v · from 12/03 · BIPOWER, Cargo trim level, MY 2005

Wiring	Colour
See 25 REAR	NERO

Pin	Cable		Destination
	Sec.	Colour	Node	Connect.	Pin
1	1,5	N		See C030 LEFT REAR EARTH	3
3	1,5	M	X	See L060C METHANE SUPPLY SOLENOID (REAR)	2
				See N040 FUEL PUMP AND LEVEL GAUGE	3
				See L060B METHANE SUPPLY SOLENOID (REAR)	2
				See L060A METHANE SUPPLY SOLENOID (REAR)	2
				See D006 FRONT/REAR COUPLING	1

I50 – Rear

1.2 8v, 1.6 16v, 1.3 JTD 16V, 1.9 JTD 8V, 1.9 DIESEL

Wiring	Colour
See 25 REAR	nero

Pin	Cable		Destination
	Sec.	Colour	Node	Connect.	Pin
1	1,5	N		See C30 LEFT REAR EARTH ( REAR )	3
3	1,5	M		See N040 FUEL PUMP AND LEVEL GAUGE	3

1.6 16v

Wiring	Colour
See 25 REAR	nero

Pin	Cable		Destination
	Sec.	Colour	Node	Connect.	Pin
1		N		See C30 LEFT REAR EARTH ( REAR )	3
3	1,5	M	X	See N040 FUEL PUMP AND LEVEL GAUGE	3
				See L60A METHANE SUPPLY SOLENOID ( REAR )	2
				See L60B METHANE SUPPLY SOLENOID ( REAR )	2
				See L60C METHANE SUPPLY SOLENOID ( REAR )	2
				See D6 FRONT REAR COUPLING ( FRONT )	1

Wiring	Colour
See 25 REAR	nero

Pin	Cable		Destination
	Sec.	Colour	Node	Connect.	Pin
1		N		See C30 LEFT REAR EARTH ( REAR )	3
3	1,5	M	X	See N040 FUEL PUMP AND LEVEL GAUGE	3
				See L60A METHANE SUPPLY SOLENOID ( REAR )	2
				See L60B METHANE SUPPLY SOLENOID ( REAR )	2
				See L60C METHANE SUPPLY SOLENOID ( REAR )	2
				See D6 FRONT REAR COUPLING ( FRONT )	1

Wiring	Colour
See 25 REAR	nero

Pin	Cable		Destination
	Sec.	Colour	Node	Connect.	Pin
1		N		See C30 LEFT REAR EARTH ( REAR )	3
3	1,5	M	X	See N040 FUEL PUMP AND LEVEL GAUGE	3
				See L60A METHANE SUPPLY SOLENOID ( REAR )	2
				See L60B METHANE SUPPLY SOLENOID ( REAR )	2
				See D6 FRONT REAR COUPLING ( FRONT )	1
