19 · Electrical

Radio - location of components

Wiring diagrams and electrical functionsRadio - location of components

RADIO - LOCATION OF COMPONENTS

1.2 8v, 1.6 16v, 1.3 JTD 16V, 1.9 JTD 8V, 1.9 DIESEL · from 10/2000, up to 10/2000 · Cargo trim level

Component code	Name	Assembly reference
B1	Engine compartment junction unit	Op. 5505A MULTI-FUNCTION COMPONENTS
B2	Junction unit under dashboard	Op. 5505A MULTI-FUNCTION COMPONENTS
C15	Facia earth, driver''s side
D20	Dashboard/rear coupling
D30	Front left door connection
D31	Front right door connection
D97	Short circuiting coupling
M1	Body computer	Op. 5505A MULTI-FUNCTION COMPONENTS
P20	Car radio	Op. 5570T CAR RADIO AND CAR TELEPHONE
P25	Aerial feeder/amplifier	Op. 5570T CAR RADIO AND CAR TELEPHONE
P30	Rear left loudspeaker (in parcel shelf)	Op. 5570T CAR RADIO AND CAR TELEPHONE
P31	Right rear speaker (in parcel shelf)	Op. 5570T CAR RADIO AND CAR TELEPHONE
P35	Speaker in left front door	Op. 5570T CAR RADIO AND CAR TELEPHONE
P36	Speaker in right front door	Op. 5570T CAR RADIO AND CAR TELEPHONE
P37	Left front speaker in dashboard	Op. 5570T CAR RADIO AND CAR TELEPHONE
P38	Right front speaker in dashboard	Op. 5570T CAR RADIO AND CAR TELEPHONE

1.2 8v, 1.6 16v, 1.3 JTD 16V, 1.9 JTD 8V, 1.9 DIESEL · from 12/03 · Cargo trim level

Component code	Name	Assembly reference
B1	Engine compartment junction unit	Op. 5505A MULTI-FUNCTION COMPONENTS
B2	Junction unit under dashboard	Op. 5505A MULTI-FUNCTION COMPONENTS
C15	Facia earth, driver''s side
D20	Dashboard/rear coupling
D30	Front left door connection
D31	Front right door connection
D97	Short circuiting coupling
M1	Body computer	Op. 5505A MULTI-FUNCTION COMPONENTS
P20	Car radio	Op. 5570T CAR RADIO AND CAR TELEPHONE
P25	Aerial feeder/amplifier	Op. 5570T CAR RADIO AND CAR TELEPHONE
P30	Rear left loudspeaker (in parcel shelf)	Op. 5570T CAR RADIO AND CAR TELEPHONE
P31	Right rear speaker (in parcel shelf)	Op. 5570T CAR RADIO AND CAR TELEPHONE
P35	Speaker in left front door	Op. 5570T CAR RADIO AND CAR TELEPHONE
P36	Speaker in right front door	Op. 5570T CAR RADIO AND CAR TELEPHONE
P37	Left front speaker in dashboard	Op. 5570T CAR RADIO AND CAR TELEPHONE
P38	Right front speaker in dashboard	Op. 5570T CAR RADIO AND CAR TELEPHONE

1.2 8v, 1.6 16v, 1.3 JTD 16V, 1.9 JTD 8V, 1.9 DIESEL · Cargo trim level, Right hand drive

Component code	Name	Assembly reference
B1	Engine compartment junction unit	Op. 5505A MULTI-FUNCTION COMPONENTS
B2	Junction unit under dashboard	Op. 5505A MULTI-FUNCTION COMPONENTS
C15	Facia earth, driver''s side
D20	Dashboard/rear coupling
D30	Front left door connection
D31	Front right door connection
D97	Short circuiting coupling
M1	Body computer	Op. 5505A MULTI-FUNCTION COMPONENTS
P20	Car radio	Op. 5570T CAR RADIO AND CAR TELEPHONE
P25	Aerial feeder/amplifier	Op. 5570T CAR RADIO AND CAR TELEPHONE
P30	Rear left loudspeaker (in parcel shelf)	Op. 5570T CAR RADIO AND CAR TELEPHONE
P31	Right rear speaker (in parcel shelf)	Op. 5570T CAR RADIO AND CAR TELEPHONE
P35	Speaker in left front door	Op. 5570T CAR RADIO AND CAR TELEPHONE
P36	Speaker in right front door	Op. 5570T CAR RADIO AND CAR TELEPHONE
P37	Left front speaker in dashboard	Op. 5570T CAR RADIO AND CAR TELEPHONE
P38	Right front speaker in dashboard	Op. 5570T CAR RADIO AND CAR TELEPHONE

1.2 8v, 1.6 16v, 1.3 JTD 16V, 1.9 JTD 8V, 1.9 DIESEL · Doblò trim level, Right hand drive

Component code	Name	Assembly reference
B1	Engine compartment junction unit	Op. 5505A MULTI-FUNCTION COMPONENTS
B2	Junction unit under dashboard	Op. 5505A MULTI-FUNCTION COMPONENTS
C15	Facia earth, driver''s side
D20	Dashboard/rear coupling
D30	Front left door connection
D31	Front right door connection
D97	Short circuiting coupling
M1	Body computer	Op. 5505A MULTI-FUNCTION COMPONENTS
P20	Car radio	Op. 5570T CAR RADIO AND CAR TELEPHONE
P25	Aerial feeder/amplifier	Op. 5570T CAR RADIO AND CAR TELEPHONE
P30	Rear left loudspeaker (in parcel shelf)	Op. 5570T CAR RADIO AND CAR TELEPHONE
P31	Right rear speaker (in parcel shelf)	Op. 5570T CAR RADIO AND CAR TELEPHONE
P35	Speaker in left front door	Op. 5570T CAR RADIO AND CAR TELEPHONE
P36	Speaker in right front door	Op. 5570T CAR RADIO AND CAR TELEPHONE
P37	Left front speaker in dashboard	Op. 5570T CAR RADIO AND CAR TELEPHONE
P38	Right front speaker in dashboard	Op. 5570T CAR RADIO AND CAR TELEPHONE
