EngineFront crank shaft cover oil seal - replace

FRONT CRANK SHAFT COVER OIL SEAL - REPLACE

Operation 1020D18 · OIL SEALS ON CRANK SHAFT

1.1

Removing

Refitting

1.2 8v

Removing

Op. 1048A10 AIR CLEANER FILTERING ELEMENT - REPLACE

Op. 5510C30 ENGINE TIMING SENSOR - R+R

Op. 4450B04 RIGHT FRONT WHEEL R R

Op. 7055B54 UNDER-ENGINE GUARD - R R

Op. 5510C26 RPM SENSOR - R+R

Op. 1092B60 ALTERNATOR DRIVE BELT - R + R

Op. 1092A10 CRANKSHAFT SERVICES PULLEY - R.R.

Op. 1032D12 TIMING SYSTEM PROTECTIVE COVER(S) - R + R

Op. 7055A42 FRONT GRILLE - R+R

Op. 1032B10 TOOTHED TIMING BELT - R + R FOR TIMING ADJUSTMENT OR REPLACEMENT

Op. 1032B44 TOOTHED DRIVE PULLEY - R + R WITH TIMING BELT REMOVED

1. Release and remove the crankshaft oil seal cover.

The oil seal is destroyed by the removal operation.

Refitting

1. Use the special fitting tool and fit the new crankshaft cover oil seal.

	Description	Code
1	Fitting tool	1.860.903.000

Op. 1032B44 TOOTHED DRIVE PULLEY - R + R WITH TIMING BELT REMOVED

Op. 1032B10 TOOTHED TIMING BELT - R + R FOR TIMING ADJUSTMENT OR REPLACEMENT

Op. 7055A42 FRONT GRILLE - R+R

Op. 1032D12 TIMING SYSTEM PROTECTIVE COVER(S) - R + R

Op. 1092A10 CRANKSHAFT SERVICES PULLEY - R.R.

Op. 1092B60 ALTERNATOR DRIVE BELT - R + R

Op. 1092B64 ALTERNATOR DRIVE BELT - ADJUST TENSION

Op. 7055B54 UNDER-ENGINE GUARD - R R

Op. 5510C26 RPM SENSOR - R+R

Op. 4450B04 RIGHT FRONT WHEEL R R

Op. 5510C30 ENGINE TIMING SENSOR - R+R

Op. 1048A10 AIR CLEANER FILTERING ELEMENT - REPLACE
