Wiring diagrams and electrical functionsHEATER - Wiring diagram
HEATER - Wiring diagram
Wiring diagram
COMPONENTS
| Component code | Name | Assembly reference |
|---|---|---|
| B1 | Engine compartment junction unit | 5505C |
| B1 | engine compartment junction unit | 5505C |
| B2 | Junction unit under dashboard | 5505C |
| C11 | Right front earth | |
| C16 | Air conditioning earth | |
| D1 | Front dashboard coupling | |
| D1 | Front / dashboard coupling | |
| D1 | front / dashboard coupling | |
| D8 | Front / air conditioning - heater coupling | |
| D8 | Front coupling air conditioner with heating | |
| D8 | Front coupling / air conditioner - with heating | |
| D97 | Short circuiting coupling | |
| G45 | Air conditioning heater controls light | |
| G45 | Air conditioning / heater controls light | |
| H1 | Ignition switch | 5520A |
| H80 | Climate control system controls | |
| M1 | Body computer | 5505A |
| N85 | Passenger compartment ventilation fan | 5020A |
| N85 | Passenger compartment ventilation fan | 5040C |
| O30 | Air fan adjustment resistance | |
| O30 | Air fan adjustment resistance | 5020A |
| O30 | Air fan adjustment resistor | |
| O30 | Air fan adjustment resistor | 5020A |
