O41 Passenger seat heater

Make

Fiat

Model

Stilo Factory Service Manual

Year

2001–2007

Section

Resistances and dimmers › O41 Passenger seat heater

Connectors and pin-outsO41 Passenger seat heater

O41 Passenger seat heater

O41A – Right seat

Wiring	Colour
37 RIGHT SEAT	GRIGIO

Pin	Cable		Destination
	Sec.	Colour	Node	Connect.	Pin
1	2,5	N		D71	4
2	2,5	GB		O41B	1

O41B – Right seat

Wiring	Colour
37 RIGHT SEAT	BIANCO

Pin	Cable		Destination
	Sec.	Colour	Node	Connect.	Pin
1	2,5	GB		O41A	2
2	2,5	B		I66

Wiring	Colour
37 RIGHT SEAT	BIANCO

Pin	Cable		Destination
	Sec.	Colour	Node	Connect.	Pin
1	2,5	GB		O41A	2
2	2,5	B		H67A
