COURTESY LIGHTS LOCATION COMPONENTS

Location Components

Components

Component code	Description	Reference to the assembly
C020	Passenger dashboard earth
C030	Left rear earth
C031	Right rear earth
D030	Left front door coupling
D031	Right front door coupling
D042	Courtesy light coupling
G010	Front courtesy light	7040E
G011	Passenger area front courtesy light	7040E
G012	Passenger area rear courtesy light	7040E
I018	Switch on left rear door
I019	Switch on right rear door
I129	Courtesy lights disabling switch
M001	Body computer	5505A
N050	Left front door lock geared motor	7005N
N051	Right front door lock geared motor	7005N
