PUDDLE LIGHTS WIRING DIAGRAM

2.0 16V JTD, 2.2 16V JTD · MY 2005

Components

Component code	Description	Reference to the assembly
B001	ENGINE COMPARTMENT JUNCTION UNIT	Op. 5505A MULTI-FUNCTION COMPONENTS
C020	PASSENGER SIDE DASHBOARD EARTH
D030	DRIVER''S FRONT DOOR COUPLING
D031	PASSENGER FRONT DOOR COUPLING
G051	LEFT FRONT DOOR LIGHT (COURTESY)	Op. 7040E INTERIOR COURTESY LIGHT SYSTEM
G052	RIGHT FRONT DOOR LIGHT (COURTESY)	Op. 7040E INTERIOR COURTESY LIGHT SYSTEM
H001	Ignition switch	Op. 5520A IGNITION SWITCH
M001	BODY COMPUTER	Op. 5505A MULTI-FUNCTION COMPONENTS
N050	LEFT FRONT DOOR LOCK GEARED MOTOR	Op. 7005N FRONT DOOR CENTRAL LOCKING SYSTEM
N051	RIGHT FRONT DOOR LOCK GEARED MOTOR	Op. 7005N FRONT DOOR CENTRAL LOCKING SYSTEM
